BMW F 800 GS User Manual

Steering and ignition
lock
Vehicle keys
You are provided with 2 ignition
keys.
Should you lose your keys please
refer to the information regarding
the electronic immobilizer (EWS)
( 37).
The ignition lock, fuel filler cap
and seat lock are operated with
the same key.
with case
OA
with Topcase
OA
The cases and the topcase can
also be ordered with locks for
the same key on request. Please
contact an authorized workshop
for this purpose, preferably an
authorized BMW Motorrad re-
tailer.
Locking handlebars
Turn handlebars to left.
Turn key to position 3 while
moving handlebars slightly.
Ignition, lights and all electrical
circuits switched off.
Handlebars locked.
Key can now be removed.
Switching on ignition
Turn key to position 1.
Parking lights and all function
circuits switched on.
Engine can be started.
Pre-Ride-Check is carried out.
( 74)
ABS self-diagnosis is
performed ( 75)
ASC self-diagnosis in progress
( 75)
4
36
z Operation

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
