BMW F 800 GS User Manual

Align two mounts 2 so that
front suspension rests securely
on them.
Tighten securing screws 1.
Apply uniform pressure to push
front wheel stand down and
raise motorcycle.
with center stand
OE
ATTENTION
Lifting-off of the center stand
if the vehicle is raised too
high
Component damage cause by
tipping over
When raising the motorcy-
cle, make sure that the center
stand remains on the ground.
Adjust the height of the front
wheel stand if necessary.
Ensure that motorcycle is
standing securely.
Engine oil
Check engine oil level
ATTENTION
Misinterpretation of the oil
filling quantity, as the oil
level is temperature-depen-
dent (the higher the tempera-
ture, the higher the oil level)
Engine damage
Only check the oil level after
a longer journey or when the
engine is warm.
Wipe area around oil fill loca-
tion to clean it.
Allow engine to idle until fan
starts, then let it continue run-
ning for an additional minute.
Switch off engine.
9
94
z Maintenance

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
