BMW F 800 GS User Manual

Press button 1 to switch on
hazard warning flashers.
Ignition can be switched off.
Press button 1 again to switch
off hazard warning flashers.
Turn indicators
Operating turn indicators
Switch on the ignition.
NOTICE
The turn indicators automati-
cally switch off when the defined
driving time and distance have
been reached. The defined rid-
ing time and distance can be set
by an authorized BMW Motorrad
retailer.
Press button 1 to left to switch
on left-side turn indicators.
Press button 1 to right to
switch on right-side turn
indicators.
Press button 1 into center po-
sition to switch off turn indica-
tors.
Display
Selecting display readings
Switching on ignition ( 36).
Press button 1 to select the
display in value area 2.
The following values can be indi-
cated:
Total kilometers (in illustration)
Trip distance 1 (Trip I)
Trip distance 2 (Trip II)
Warnings if necessary
4
40
z Operation

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
