Brother MFC-J6545DW User Manual

3-4
Confidential
4 SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening
N•m (kgf•cm)
MP tray ASSY TAPTITE CUP B M4x12 2 0.70±0.10 (7±1)
MP tray cover (India model) TAPTITE CUP B M3x10 2 0.45±0.05 (4.5±0.5)
Top cover ASSY TAPTITE BIND B M4x12 2 0.70±0.10 (7±1)
FB hinge TAPTITE BIND B M4x12 6 0.80±0.10 (8±1)
ADF FG wire SCREW BIND M3x6 1 0.35±0.05 (3.5±0.5)
ADF document size sensor FG wire
FB FG wire SCREW BIND M3x6 1 0.35±0.05 (3.5±0.5)
Document scanner unit TAPTITE BIND B M4x12 2 0.70±0.10 (7±1)
Document scanner side cover L TAPTITE CUP B M3x10 1 0.50±0.05 (5±0.5)
Document scanner side cover R TAPTITE CUP B M3x10 1 0.50±0.05 (5±0.5)
ADF unit TAPTITE BIND B M4x12 M9 2 0.80±0.10 (8±1)
ADF front cover TAPTITE CUP B M3x10 4 0.50±0.05 (5±0.5)
ADF separation pad holder ASSY TAPTITE CUP B M3x10 1 0.40±0.05 (4±0.5)
ADF document size sensor FG wire 1 TAPTITE CUP B M3x10 1 0.50±0.10 (5±1)
ADF document size sensor FG wire 2
ADF unit TAPTITE CUP B M2.6x10 3 0.30±0.05 (3±0.5)
Document cover top ASSY TAPTITE CUP B M3x10 6 0.40±0.05 (4±0.5)
TAPTITE CUP B M3x12 2 0.40±0.05 (4±0.5)
Document cover base TAPTITE BIND B M3x14 2 0.50±0.10 (5±1)
ADF hinge TAPTITE CUP B M3x10 6 0.40±0.05 (4±0.5)
Exit support plate TAPTITE CUP B M3x10 1 0.50±0.05 (5±0.5)
Lower doc chute ASSY TAPTITE CUP B M3x10 2 0.40±0.05 (4±0.5)
Scanner top cover ASSY TAPTITE CUP B M2.6x10 4 0.30±0.05 (3±0.5)
Document cover sensor TAPTITE CUP B M3x10 1 0.50±0.10 (5±1)
Front cover L TAPTITE BIND B M4x12 1 0.60±0.05 (6±0.5)
Upper cover TAPTITE BIND B M4x12 6 0.60±0.05 (6±0.5)
FG wire TP SCREW CUP M3x6 1 0.35±0.05 (3.5±0.5)
Tilt cover (screwed to Tilt holder and
Lower cover)
TAPTITE CUP B M3x10 1 0.35±0.05 (3.5±0.5)
Tilt cover (screwed to Tilt holder) TAPTITE CUP B M3x10 1 0.65±0.05 (6.5±0.5)
Tilt hook TAPTITE CUP B M3x8 2 0.35±0.05 (3.5±0.5)
Panel lower cover TAPTITE CUP B M2.6x10 3 0.30±0.05 (3±0.5)
Main PCB shield SCREW CUP M3x6 2 0.35±0.05 (3.5±0.5)
Main PCB SCREW CUP M3x6 1 0.35±0.05 (3.5±0.5)
TAPTITE CUP B M3x10 1 0.35±0.05 (3.5±0.5)
Upper modem frame SCREW CUP M3x6 1 0.35±0.05 (3.5±0.5)
Modem PCB SCREW CUP M3x6 1 0.35±0.05 (3.5±0.5)
Lower side cover R TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)

Brother MFC-J6545DW Specifications

General

Type	all in one, fax
Color	white/gray, white
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	350
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
First Page Print Time	6 seconds
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	letter-size glossy inkjet paper; 4" x 6" glossy photo paper; letter-size multi-purpose paper
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Duplex Scan	no
Max Copies	999
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3037bk, lc3037c, lc3037m, lc3037y, lc3039bk, lc3039c, lc3039m, lc3039y
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, ethernet, google cloud print, mopria print service, usb 2.0, wi-fi, wi-fi direct
Mobile Devices Connection	yes

Weight and Dimensions

Depth	22.6 inches
Height	12.2 inches
Width	22.6 inches
Net Weight	44.3 pounds
