Brother MFC-J6545DW User Manual

Confidential
2-54
■ Error Code AF00
CIS positioning abnormal (Home position cannot be found)
■ Error Code BF00
Document scanning position sensor detects that the document’s length does not fit
duplex scanning.
< User Check >
- Check whether the document scanned is longer than the specified limit.
- Remove the jammed document.
■ Error Code D100
Modem PCB initialization failed.
Error Code D200
SDAA communication failure
Step Cause Solution
1 Scanner belt out of place Set the scanner belt into place.
2 Scanner motor harness
connection failure
Reconnect the scanner motor harness.
3 First side CIS flat cable
connection failure
Reconnect the first side CIS flat cable.
4 Black reference film stained Clean document cover glass at black reference
film.
5 First side CIS flat cable
defective
Replace the first side CIS flat cable.
6 First side CIS unit defective Replace the first side CIS unit.
7 Scanner motor defective Replace the document scanner unit.
8 Main PCB defective Replace the main PCB.
Step Cause Solution
1 Document scanning position
actuator caught on the
surrounding parts
Set the document scanning position actuator
into place.
2 Document scanning position
sensor defective
Replace the document scanning position
sensor PCB.
3 Document feed roller worn out Replace the ADF unit.
4 Main PCB defective Replace the main PCB.
Step Cause Solution
1 Modem PCB harness
connection failure
Reconnect the modem PCB harness.
2 Modem PCB defective Replace the modem PCB.
3 Main PCB defective Replace the main PCB.

Brother MFC-J6545DW Specifications

General

Type	all in one, fax
Color	white/gray, white
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	350
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
First Page Print Time	6 seconds
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	letter-size glossy inkjet paper; 4" x 6" glossy photo paper; letter-size multi-purpose paper
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Duplex Scan	no
Max Copies	999
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3037bk, lc3037c, lc3037m, lc3037y, lc3039bk, lc3039c, lc3039m, lc3039y
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, ethernet, google cloud print, mopria print service, usb 2.0, wi-fi, wi-fi direct
Mobile Devices Connection	yes

Weight and Dimensions

Depth	22.6 inches
Height	12.2 inches
Width	22.6 inches
Net Weight	44.3 pounds
