■ Error Code 4300
Head thermistor defective
- Head thermistor detects -20 degree-C or less, or 80 degree-C or more when power
is ON.
■ Error Code 4400
Head driver IC detects abnormal temperature during operation or stand-by.
■ Error Code 4600
Purge count or flushing count overflown.
■ Error Code 4800
Head flat cable detected to be not correctly inserted.
Step Cause Solution
1 Carriage flat cable connection
failure
Reconnect the carriage flat cable.
2 Head thermistor defective Replace the head/carriage unit.
3 Main PCB defective Replace the main PCB.
Step Cause Solution
1 Carriage flat cable connection
failure
Reconnect the carriage flat cable.
2 Head property information not
input
Input the head property information (refer to
Chapter 5, Section 1.3.24 "Updating of Head
Property Information and Backup/Restoration of
Head Calibration Data (Maintenance mode
68)")
3 Head thermistor defective
Head defective
Replace the head/carriage unit.
4 Main PCB defective Replace the main PCB.
Step Cause Solution
1 Ink absorber box or flushing
box full.
Replace ink absorber box or flushing box,
resetting purge counter or flushing counter.
2 Main PCB defective Replace the main PCB.
Step Cause Solution
1 Carriage flat cable connection
failure
Reconnect the carriage flat cable.
2
Head flat cable connection
failure
Reconnect the head flat cable.
3 Carriage PCB defective Replace the carriage PCB ASSY.
4 Head defective Replace the head/carriage unit.
5 Main PCB defective Replace the main PCB.

Brother MFC-J6545DW Specifications

General

Type	all in one, fax
Color	white/gray, white
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	350
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
First Page Print Time	6 seconds
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	letter-size glossy inkjet paper; 4" x 6" glossy photo paper; letter-size multi-purpose paper
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Duplex Scan	no
Max Copies	999
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3037bk, lc3037c, lc3037m, lc3037y, lc3039bk, lc3039c, lc3039m, lc3039y
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, ethernet, google cloud print, mopria print service, usb 2.0, wi-fi, wi-fi direct
Mobile Devices Connection	yes

Weight and Dimensions

Depth	22.6 inches
Height	12.2 inches
Width	22.6 inches
Net Weight	44.3 pounds
