■ Error Code 3C00
Abnormal stop of head/carriage unit being driven.
- Caused by paper jam when ink is discharging.
< User Check >
- Remove the jammed paper in platen part.
■ Error Code 3E00
Defective occurs in the ASF motor, carriage motor or paper feed motor.
Step Cause Solution
1
Foreign materials in the engine unit Remove foreign materials.
2 CR encoder strip stained Clean the CR encoder strip.
3 CR encoder strip defective Replace the CR encoder strip.
4 CR encoder sensor defective Replace the carriage PCB ASSY.
5 Main PCB defective Replace the main PCB.
Step Cause Solution
1 Foreign materials in the
recording paper path
Remove foreign materials.
2 Foreign materials in the
maintenance unit
Remove foreign materials.
3 Foreign materials around
paper feed roller belt
Remove foreign materials.
4 Foreign materials around
paper ejection roller belt
Remove foreign materials.
5
Foreign materials in the engine unit Remove foreign materials.
6 Maintenance unit not mounted
in place
Set the maintenance unit into place.
7
Flushing box not mounted in place Set the flushing box into place.
8
CR guide rail not mounted in place Set the CR guide rail into place.
9 Platen not mounted in place Set the platen into place.
10 Head/carriage unit not
mounted in place
Set the head/carriage unit into place.
11 CR encoder strip defective Replace the CR encoder strip.
12 PF encoder disk defective Replace the PF encoder disk.
13 PF encoder sensor defective Replace the PF encoder sensor.
14 CR encoder sensor defective Replace the carriage PCB ASSY.
15 Carriage motor defective Replace the carriage motor.
16 Paper feed motor defective Replace the paper feed motor.
17 ASF motor defective Replace the maintenance unit.
18 Main PCB defective Replace the main PCB.

Brother MFC-J6545DW Specifications

General

Type	all in one, fax
Color	white/gray, white
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	350
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
First Page Print Time	6 seconds
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	letter-size glossy inkjet paper; 4" x 6" glossy photo paper; letter-size multi-purpose paper
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Duplex Scan	no
Max Copies	999
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3037bk, lc3037c, lc3037m, lc3037y, lc3039bk, lc3039c, lc3039m, lc3039y
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, ethernet, google cloud print, mopria print service, usb 2.0, wi-fi, wi-fi direct
Mobile Devices Connection	yes

Weight and Dimensions

Depth	22.6 inches
Height	12.2 inches
Width	22.6 inches
Net Weight	44.3 pounds
