1.3.19 Checking of CIS Travel and Specifying of CIS Type (Maintenance mode 59)
< Function >
This procedure allows you to check the movement of the CIS unit integrated in the
document scanner unit.
The CIS unit travels to the three positions – the ADF scanning position, FB scanning
start and end positions.
It also allows you to specify the CIS type into the EEPROM on the main PCB. If you
replace the main PCB, you need to specify the CIS type according to the procedure
given below.
< Operating Procedure >
Check the movement of the CIS unit
(1) Press the 5 and 9 keys in this order in the initial stage of the maintenance mode.
The machine displays the "1:MO 2:CO 3:CHG?" on the LCD.
(2) Press the 1 key.
Duplex scanning models: The "1:FB 2:ADF 3:BTH" appears on the LCD. Press the
1 key.
Simplex scanning models: Go to step (3).
(3) The "1:30 2:60 3:12?" appears on the LCD. Press the 1 key. Press the SET key
repeatedly until the “1: ADF 2: FRT 3: MV” appears on the LCD.
(4) Press the 1 key and then press the SET key to move to the ADF scanning position.
Press the 2 key and then press the SET key to move to the FB scanning start
position.
Press the 3 key and then press the SET key to move to the FB scanning end
position.
(5) To return the machine to the initial stage of the maintenance mode, press the X
key.
Specify the CIS type
(1) Press the 5 and 9 keys in this order in the initial stage of the maintenance mode.
The machine displays the "
1:MO 2:CO 3:CHG?" on the LCD.
(2) Press the 3 key.
Duplex scanning models: The "1:FB 2:ADF?" appears on the LCD.
To specify the type of the first side CIS, press the 1 key; to specify that of the
second side CIS, press the 2 key.
Simplex scanning models: Go to step (3).
(3) The "1:AUTO 2:MANUAL?" appears on the LCD.
(4) Press the 1 key.
The machine automatically sets the CIS type and returns to the initial stage of the
maintenance mode.
If the completion of automatic setting of the CIS type results in mismatch between
the built-in CIS unit and the firmware setting, the "PLS UPDATE PROG" appears
on the LCD. If this happens, load the latest firmware.
Note: If a failure in the automatic setting of the CIS type results in machine error
AF00, press the 2 key in step (3) and specify the CIS type manually. When
“CIS TYPE*
→” is displayed on the LCD (where * indicates the automatically
set CIS type), enter the CIS type (0 or 1).

Brother MFC-J6545DW Specifications

General

Type	all in one, fax
Color	white/gray, white
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	350
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
First Page Print Time	6 seconds
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	letter-size glossy inkjet paper; 4" x 6" glossy photo paper; letter-size multi-purpose paper
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Duplex Scan	no
Max Copies	999
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3037bk, lc3037c, lc3037m, lc3037y, lc3039bk, lc3039c, lc3039m, lc3039y
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, ethernet, google cloud print, mopria print service, usb 2.0, wi-fi, wi-fi direct
Mobile Devices Connection	yes

Weight and Dimensions

Depth	22.6 inches
Height	12.2 inches
Width	22.6 inches
Net Weight	44.3 pounds
