1.3.17 Cartridge IC Communication Check (Maintenance mode 57)
< Function >
This function checks the applicable cartridge, color information, destination, size and
data version in the IC chip built in an ink cartridge.
< Operating Procedure >
(1) Press the 5 and 7 keys in this order in the initial stage of the maintenance mode.
The "IC_ACT ALL" appears on the LCD.
To check whether the cartridge is applicable,
press the 1 key.
The "IC_ACT ALL" appears on the LCD.
To check the color information of the cartridge,
press the 2 key.
The "IC_COL ALL" appears on the LCD.
To check the destination of the cartridge,
press the 3 key.
The "IC_AREA ALL" appears on the LCD.
To check the cartridge size,
press the 4 key.
The "IC_SIZE ALL" appears on the LCD.
To check the data version of the cartridge,
press the 5 key.
The "IC_VER BLACK" appears on the LCD.
(2) Select the slot number of the cartridge to be checked, using the or key.
ALL: all colors (except MAIN)
BLACK: black
MAGENTA: magenta
CYAN: cyan
YELLOW: yellow
MAIN: IC chip in the machine
Note: The color displayed on the LCD indicates not the cartridge color but the
cartridge slot color position.
(3) Press the Mono Start key.
If checking is successfully completed, the LCD shows "OK."
If any error is detected, the LCD shows the corresponding error code as shown
below. Press the X key to return the machine to the initial stage of the maintenance
mode.
Display Causes
NG0 to NG99 Failure of IC integrated in the machine
NG100 to NG199
No response from the IC
- Ink cartridge not loaded
- No IC in the ink cartridge
- IC contact defective
NG200 to NG299 Wrong response result from the IC
NG300 to NG399
Succeeded in verifying IC, but the information judged as
mismatching
- Loading mistake

Brother MFC-J6545DW Specifications

General

Type	all in one, fax
Color	white/gray, white
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	350
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
First Page Print Time	6 seconds
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	letter-size glossy inkjet paper; 4" x 6" glossy photo paper; letter-size multi-purpose paper
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Duplex Scan	no
Max Copies	999
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3037bk, lc3037c, lc3037m, lc3037y, lc3039bk, lc3039c, lc3039m, lc3039y
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, ethernet, google cloud print, mopria print service, usb 2.0, wi-fi, wi-fi direct
Mobile Devices Connection	yes

Weight and Dimensions

Depth	22.6 inches
Height	12.2 inches
Width	22.6 inches
Net Weight	44.3 pounds
