APPENDIX ——————————————————————————————————————————————————————————————————————————
——
240
Using the Optional Bobbin Winder
When winding the bobbin thread onto a metal bobbin, use the optional bobbin winder. The procedures for
using the optional bobbin winder are described below.
Precautions
For precautions concerning the power supply, refer to page 32.
CAUTION
Optional bobbin winder and its accessories
Check that the following bobbin winder and accessories are included.
• The part code of the bobbin winder set may differ depending on the country/area where the
machine was purchased.
●
Be sure to place the bobbin winder on a level, stable surface.
● Only use the bobbins supplied with this bobbin winder.
1. 2. 3. 4.
5.
1 Main power switch
2 Bobbin winder shaft
3 Hole for thread guide
4 Hole for spool pin
5 DC input connector
6. 7. 8. 9.
10.
No. Name Part Code No. Name Part Code
1 Bobbin winder PRBW1 6 Power supply cord Visit your nearest
authorized dealer.
2 Spool pin XC5949-051 7 Metal bobbin × 5 100376-053
3 Spool cushion XA0679-050 8 Spool cap 130012-054
4 Thread guide XC6644-151 9 Weight (L) XC5974-151
5 AC adapter Visit your nearest
authorized dealer.
10 Weight (S) XC6631-051
