Specifying Embroidering Setting 45
2
——
—————————————————————————————————————————————————————————————
—
—————————————————————
5. Specifying Embroidering Setting
From this screen, the entire pattern can be edited and embroidering settings can be specified. In addition,
the embroidering position can be checked and a pattern can be saved for later use.
Embroidering settings screen (For details on the keys and other information on the screen, refer to page 75.)
1 Displays a preview image.
2 Touch to edit the pattern.
3 Returns to the pattern editing screen.
4 In the embroidering settings screen, the
embroidery frame guide in the pattern display
area indicates the size of the installed
embroidery frame.
5 Touch these keys to specify how the pattern will
be embroidered.
6 Touch to store the pattern in memory.
7 Continues to the next screen
8 Touch to check the embroidering area.
In this example, we will not specify any of the
embroidering settings. Continue with the next
operation.
Memo
● If the embroidery frame is not positioned
correctly when continuing to the
embroidering settings screen, the
embroidery frame is moved to the correct
position at the same time that the
embroidering settings screen is displayed.
(Refer to “Moving to the correct position”
on page 95.)
1
2
7
4
5
6
8
3

Brother PR-650 Specifications

General

Display	LCD
Free arm	Yes
Interface	USB
Control type	Sensor
Sewing speed	1000
Product color	White
Buttonhole type	4 Step
Number of programs	25
Sewing machine functions	Embroidery
Number of needle positions	6
