EMBROIDERING TUTORIAL
——————————————————————————————————————————————————————————————
70
Screen Quick Reference Guide
Descriptions of the keys and other information that appear in the screens are provided in the tables below.
Key displays
The appearances of the keys have the following meanings.
Common screen controls
The keys described below, except for the settings key, appear in all screens and can always be used.
However, the settings key cannot be used in the embroidering screen.
(Normal color display) : This key is not selected, but can be selected.
(Dark-colored display) : This key is selected.
(Gray display) : This key cannot be selected.
No.
Display
Function Page
Key Name
1
This area displays the
selected pattern.
Pattern
display area
2
Shows the
embroidering area for
the extra-large
embroidery frame.
The embroidery frame
indications, the grid
lines and other display
settings can be
specified from the
machine settings
screen.
p. 196
Embroidering
area line
3
Touch this key to
check a machine
operation.
p.206
Machine
operations
guide key
4
Touch this key to
change the
embroidery machine
settings.
p.194
Settings key
5
Touch this key to
cancel all operations
previously performed
and return to the
initial pattern group
selection screen.
Home key
6
Touch this key to
move or thread a
selected needle bar.
This key is available
in any screen.
p. 61
Needle bar
move key
No.
Display
Function Page
Key Name
