Setting Up the Machine 25
1
——————————————————————————————————————————————————————
————————————————————————————
Setup location
Setup the machine in a location that meets the following requirements.
• Position machine more than 50 mm (2 inches) from the wall
• Allow sufficient space around the machine
• Place no objects within the moving range of the embroidery frame
• Set-up machine near an electrical outlet
• Use a level and stable surface, such as a desk
• Use a surface that can support the weight of the machine (about 37 kg (81 lb))
• Allow open space around the ventilation slots found on the rear underside of the machine
CAUTION
● For your safety: Since the machine weighs approximately 37 kg (81 lb), do not set it up on an
unstable table or desk.
770 mm
(30-5/16
inches)
More than
50 mm
(2 inches)
589 mm
(23-3/16 inches)
More than
350 mm
(13-3/4 inches)
More than
250 mm
(9-7/8 inches)
512 mm
(20-5/32 inches)
More than
250 mm
(9-7/8 inches)
● In order to prevent malfunctions or damage, do not set up the machine in a location
exposed to the following conditions.
Liquids, such as water Extreme dust
Direct sunlight
Blocked ventilation slots
Insufficient space
Objects within the moving range of
the embroidery frame
An unstable surface
Extremely high or extremely low
temperatures. The operating
environment should be between
5 °C (40 °F) and 40 °C (104°F).
Connection to extension
cords or multiple
adapters
To Next Page
