Cisco Catalyst 3560-X User Manual

1-46
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring Interface Characteristics
Configuring the Power Supplies
Configuring the Power Supplies
You can use the power supply user EXEC command to configure and manage the internal power
supplies on the switch.
To configure and manage the internal power supplies, follow these steps beginning in user EXEC mode:
The switch does not support the no power supply user EXEC command. To return to the default setting,
use the power supply switch-number slot {A | B} on}command.
For more information about using the power supply user EXEC command, see the command reference
for this release.
Configuring the Cisco RPS 2300 in a Mixed Stack
In a mixed stack with Catalyst 3750-X and 3750-E switches, one or more Catalyst 3750-E switches can
be connected to a Cisco Redundant Power System 2300, also known as the RPS 2300. You can configure
and manage an RPS 2300 connected to a Catalyst 3750-E switch in the stack.
Note The Catalyst 3750-X and 3560-X switches do not have RPS connectors. These switches can be
connected to an XPS-2200 expandable power supply (not available at this time). The Catalyst 3750-X
switch also has stack power connectors. See Chapter 1, “Configuring Catalyst 3750-X StackPower” for
information on stack power.
Command Purpose
Step 1
power supply switch-number {reset {hard | soft} slot {A |
B} {off | on}}
Specifies a switch to reset or a power supply to set
to off or on. By default, the switch power supply is
on.
• reset—Resets the software or switch:
– hard—Resets everything on the switch,
including the hardware.
– soft—Resets only the switch software.
• slot A —Selects the power supply in slot A.
• slot B —Selects power supply in slot B.
Note Power supply slot B slot is the closest to the
outer edge of the switch.
• off—Sets the power supply off.
• on—Sets the power supply on.
The switch-number is supported only on
Catalyst 3750-X switches.
Step 2
show env power Verifies your settings.
Step 3
copy running-config startup-config (Optional) Saves your entries in the configuration
file.
