Page #339 background image
show tech-support routing ospfv3
To automatically run show commands that display information specific to Open Shortest Path First Version
3 (OSPFv3) debugging, use the show tech-support routing ospfv3 command in EXEC mode.
show tech-support routing ospfv3 [ instance ] [detail] {terminal [page]| file send-to [background]
[compressed| uncompressed]}
Syntax Description
(Optional) Name of the OSPFv3 instance.
instance
(Optional) Displays all available OSPFv3 information.detail
Displays the command output on the terminal.terminal
(Optional) Displays the command output on a single page at a time. Use the
Return key to display the next line of output or use the space bar to display the
next page of information. If not used, the output scrolls (that is, it does not stop
for page breaks).
Press the Ctrl-C keys to stop the command output.
page
Specifies that the command output is saved to a specified file.file
Name of the file. The following valid options are listed:
•
filename
•
bootflash: filename
•
compactflash: filename
•
disk0: filename
•
disk1: filename
•
flash: filename
•
ftp: filename
•
harddisk: filename
•
harddiska: filename
•
nvram: filename
•
rcp: filename
•
slot0: filename
•
slot1: filename
•
tftp: filename
sent-to
(Optional) Specifies that the command runs in the background.background
Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x
OL-30353-01 331
Tech-Support Commands
show tech-support routing ospfv3
