Using the Modem While Traveling
Internationally
Using a Country-Specific Modem Adapter
Telephone jacks vary by country. The modem cable included with
the computer plugs directly into an RJ-11 telephone jack. To plug
the modem cable into a different type of telephone jack, you must
use a country-specific modem cable adapter. A cable adapter is
provided with the computer. To obtain the country-specific
adapters required for your itinerary, refer to Appendix A to contact
a Compaq-authorized dealer, reseller, or service provider.
To connect the modem using a country-specific modem adapter:
1. Plug the end of the modem cable with the EMI suppression
circuitry included with the computer into the RJ-11 jack on the
computer
1 .
2. Plug the country-specific modem adapter into the telephone
jack
2 .
3. Plug the modem cable into the country-specific modem
adapter
3 .
