Model
Parameters
HCVR7204AN-4M
HCVR7208AN-4M
HCVR7216AN-4M
USB
2 USB ports(One USB2.0 port at the front panel and one USB3.0 port
at the rear panel)
Others
Power
DC12V
Power
Consumption (No
HDD)
≤12W
≤13W
≤20W
Working
Temperature
-10℃～＋55℃
Working Humidity
10%~90%
Dimensions
1U case, 375mm（W）×280mm（D）×50mm（H）
Weight （No HDD）
≤1.60KG
≤1.60KG
≤1.75KG
Installation Mode
Desk
1.3.55 XVR410XC Series
Parameters
XVR4104C
XVR4108C
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode Resolution
1080N/720P/960H/D1/HD1/2CIF/CIF
1080N@12f/720P@15f
/960H/D1/HD1/2CIF/CIF
Video Frame Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-4096Kbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video Input
4-ch BNC port(CVBS/CVI/AHD/ other
analog HD video self-adaptive)
8-ch BNC port(CVBS/CVI/
AHD/other analog HD video
self-adaptive)
Network Video Input

There is no IP channel by default.
Max add 1 IP channel
connection

Analog/digital channel switch.
Max 5 IP channel connections

Connection
bandwidth:0Mbps-20Mbps

There is no IP channel
by default.Max add 2 IP
channel connections

Analog/digital channel
switch. Max 10 IP
channel connections

Connection
bandwidth:0Mbps-40M
bps
Video Output
1-channel VGA output,
