50
Parameters
HCVR5104HS3
HCVR5108H-S3
HCVR5116H-S3
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
8-channel input
8-channel input
16-channel input
Alarm Output
3-channel output
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One
at the front panel and
one at the rear panel)
1 USB2.0 port at the
front panel and one
USB3.0 port at the
rear panel
1 USB2.0 port at
the front panel
and one USB3.0
port at the rear
panel
Others
Power
DC12V
Power
Consumption
≤8W
≤10W
≤15W
Working
Temperature
-10℃~+55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case,325mm(W)×245mm(D)×45mm(H)
Weight
≤1.1KG
≤1.25KG
≤1.45KG
Installation
Mode
Desk
1.3.27 HCVR51XXHE-S3 Series
Parameters
HCVR5104HE-S3
HCVR5108HE-S3
HCVR5116HE-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P@12f/720P@15f/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-6144Kbps,
For 720P: default setup is 2Mbps,max supports 4Mbps.
