Dahua XVR5216A User Manual

113
Parameters
XVR7104H
XVR7108H
XVR7116H
USB
2 USB2.0 ports(One
at the front panel and
one at the rear panel)
1 USB2.0 port and 1 USB3.0 port (One
USB2.0 port at the front panel and one
USB3.0 port at the rear panel)
Others
Power
DC12V
Power
Consumption
≤8W
≤10W
≤15W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case,325mm（W）×245mm（D）×45mm（H）
Weight
≤1.1KG
≤1.25KG
≤1.45KG
Installation
Mode
Desk
1.3.63 XVR21XXHS Series
Parameters
XVR2104HS
XVR2108HS
XVR2116HS
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080N@12f/720P@12f/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-4096Kbps
Bit Stream Type
Video stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
N/A
Audio Sampling
Rate
N/A
Audio Bit Rate
N/A
Video Port
Analog Video
Input
4-ch BNC
port(CVBS/CVI/AHD
/other analog HD
video self-adaptive)
8-ch BNC
port(CVBS/CVI/AHD
/other analog HD
video self-adaptive)
16-ch BNC
port(CVBS/CVI/AHD
/other analog HD
video self-adaptive)
Network Video
Input

There is no IP
channel by
default. Max
add 0 IP
channel

There is no IP
channel by
default. Max
add 0 IP
channel

There is no IP
channel by
default. Max
add 0 IP
channel
