Dahua XVR5216A User Manual

107
Parameters
XVR5104H
XVR5108H
XVR5116H
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one
at the rear panel)
1 USB2.0 port
and 1 USB3.0
port (One
USB2.0 port at
the front panel
and one USB3.0
port at the rear
panel)
Others
Power
DC12V
Power
Consumption
≤7W
≤8W
≤10W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case,325mm（W）×245mm（D）×45mm（H）
Weight
≤1.1KG
≤1.25KG
≤1.45KG
Installation
Mode
Desk
1.3.60 XVR51XXHE Series
Parameters
XVR5104HE
XVR5108HE
XVR5116HE
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P@15f/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-6144Kbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(CVBS/CVI/AHD
/other analog HD
8-ch BNC
port(CVBS/CVI/AHD
/other analog HD
16-ch BNC
port(CVBS/CVI/A
HD /other analog
