The account for you to access the FTP server.
The folder you created under the root path of the FTP according to the
corresponding rule.
If there is no remote directory, system can auto create different
directories according to the IP, time and channel.
If there is remote directory, system can create corresponding folder
under the FTP root path and then create different folders according
to IP address, time and channel.
File length is upload file length. When setup is larger than the actual file
length, system will upload the whole file. When setup here is smaller
than the actual file length, system only uploads the set length and auto
ignore the left section. When interval value is 0, system uploads all
corresponding files.
It is the image upload interval. If the image upload interval is larger than
the image snapshot frequency, system just uploads the lasted image.
If the image interval is 5 seconds and the snapshot frequency is 2
seconds, system will send out the latest image at the buffer at 5
seconds.
If the image upload interval is smaller than the snapshot frequency,
system will upload at the snapshot frequency. For example, if the
image interval is 5 seconds and the snapshot frequency is 10
seconds, system will send out the image at 10 seconds.
From main menu->Setting->Camera->Encode->Snapshot to set
Select a channel from the dropdown list and then set week, period and
record type.
Please select from the dropdown list and for each day, you can set two
periods.
Please select uploaded record type (Alarm/intelligent/motion
detect/regular). Please check the box to select upload type.
If the operation successful, device says FTP test successful.
If the operation failed, device says FTP test failed. Please check network
connection and settings.
Step 5 Click Save to complete the setup.
The interface is shown as in Figure 5- 107.
