Dell EMC PowerEdge R7515 Service Manual

NOTE: Use alpha wire part number 3080 or equivalent (65/30 stranding).
Optional front bezel
NOTE: LCD panel is optional on the front bezel. If the front bezel has an LCD panel, see LCD panel section.
Removing the front bezel
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions on page 26.
NOTE: The bezel key is part of the bezel package.
Steps
1. Unlock the bezel .
2. Press the release button, and remove the left end of the bezel.
3. Slide the tabs on the right end of the bezel out of the slots on the chassis and remove the bezel.
Figure 17. Removing the front bezel
Installing the front bezel
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions on page 26.
NOTE: The bezel key is part of the bezel package.
28 Installing and removing system components
