Dell EMC PowerEdge R7515 Service Manual

Figure 90. Removing the accelerator card from riser 1B
4. Install a filler bracket if you are not replacing the expansion card. For information about how to install a filler bracket, see
installing a filler bracket section in the Removing the expansion card topic.
Next steps
1. Install an accelerator card.
Installing an accelerator card
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions on page 26.
2. Follow the procedure listed in the Before working inside your system on page 27.
3. If installing a new expansion card, unpack it and prepare the card for installation.
NOTE: For instructions, see the documentation accompanying the card.
4. Install the air shroud.
Steps
1. Pull and lift to open the expansion card retention latch lock.
2. If installed, remove the filler bracket. For information about how to remove filler bracket, see the removing a filler bracket
section in the Installing an expansion card topic.
3. Hold the card by the edges, align with the connector on the expansion card riser and press until the card is seated in place.
Installing and removing system components
87

Dell EMC PowerEdge R7515 Specifications

General

Maximum Processors	1
Cores per Processor	Up to 64
Processor	AMD EPYC 7002 Series
Memory Type	DDR4
Memory Slots	16 DIMM slots
Storage	Up to 12 x 3.5" SAS/SATA or up to 24 x 2.5" SAS/SATA/NVMe drives
RAID Support	PERC H345, H745
Network Options	1GbE, 10GbE, 25GbE
Network Controller	1 x 1GbE LOM
Power Supply	750W, 1100W
Form Factor	2U Rack
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
