5. Remove the display bezel.
6. Remove the display panel.
About this task
The following images indicate the location of the sensor board and provide a visual representation of the removal procedure.
NOTE: The following steps are applicable only for clamshell systems.
Steps
1. Open the latch and disconnect the display cable from connector on the sensor board.
2. Gently lift the sensor board away from the display back cover.
Installing the sensor board
About this task
The following images indicate the location of the sensor board and provide a visual representation of the removal procedure.
NOTE: The following step are applicable only for clamshell systems.
106 Removing and installing components
