Steps
1. Align the tabs on the battery with the tab holders on the 3-cell battery filler.
2. Slide the 3-cell battery filler to the battery.
3. Place the battery on the palm-rest assembly and align the screw holes on the battery with the screw holes on the palm-rest
assembly.
4. Tighten the three captive screws to secure the battery in place.
5. Connect the battery cable to the system board.
Next steps
1. Install the base cover.
2. Follow the procedure in after working inside your computer.
Removing the 4-cell battery
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the base cover.
About this task
NOTE: Latitude 5330 supports 3-cell 41 WHr and 4-cell 58 WHr battery configuration.
The following image indicates the location of the 4-cell 58 WHr battery and provides a visual representation of the removal
procedure.
