Table 1. Screw list (continued)
Component Screw type Quantity Screw image
M2x4 1
Power button/Power button
with optional fingerprint reader
M2x2 1
Smart card reader M2x2 4
LED board M2x3 1
Keyboard assembly M2x2 18
Keyboard bracket M2x2 2
Display assembly M2.5x4 (display hinge to
palm-rest assembly)
M2x4 (display cable
bracket to palm-rest
assembly)
4
1
Display hinge M2.5x3 (display hinge to
display back cover)
6
Display panel M2x2.5 2
Major components of Latitude 5330
The following image shows the major components of Latitude 5330.
Removing and installing components
11
