1. Base cover 2. Battery
3. 3-cell battery filler 4. System board
5. Keyboard assembly 6. Coin-cell battery
7. Speaker 8. Battery frame left/right
9. Smart-card reader 10. Palm-rest assembly
11. Display assembly 12. LED board
13. Solid-state drive 14. Power button with optional fingerprint reader
15. Solid-state drive bracket 16. WLAN card
17. WWAN card 18. System fan
19. Heat sink
NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These
parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for
purchase options.
SIM card tray
Removing the SIM card tray
Prerequisites
Follow the procedure in before working inside your computer.
About this task
The following image provides a visual representation of the SIM card tray removal procedure.
Removing and installing components
13
