Dell P138G User Manual

The figure provides a visual representation if you are replacing a M.2 2230 solid-state drive with a M.2 2280 solid-state drive.
NOTE: Ensure the M.2 2230 solid-state drive is removed first. See the procedure for removing the M.2 2230 solid-state
drive.
Steps
1. Lift and slide the solid-state drive holder over the hook to remove it.
2. Depending on the type of solid-state drive (M.2 2230/ M.2 2280), align and insert the solid-state drive holder.
3. Install the solid-state drive.
Removing the M.2 2230 solid-state drive
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the base cover.
Removing and installing components
39
