2. Install the display bezel.
3. Install the display assembly.
4. Install the 3-cell battery or 4-cell battery.
5. Install the base cover.
6. Follow the procedure in after working inside your computer.
eDP cable
Removing the eDP cable
Prerequisites
NOTE: The eDP cable removal procedure is applicable only for Latitude 5330 laptop and not for the 2-in-1 configuration.
1. Follow the procedure in before working inside your computer.
2. Remove the base cover.
3. Remove the 3-cell battery or 4-cell battery.
4. Remove the display assembly.
5. Remove the display bezel.
6. Remove the display hinges.
7. Remove the display panel.
About this task
The following images indicate the location of the eDP cable and provide a visual representation of the removal procedure.
Removing and installing components
97
