4. Follow the procedure in after working inside your computer.
Display panel
Removing the display panel
Prerequisites
NOTE: The display panel removal procedure is applicable only for Latitude 5320 laptop and not for the 2-in-1 configuration.
NOTE: The display panel and its support brackets are defined as a single assembly and cannot be further disassembled once
it is removed from the display back cover. The support brackets are not to be removed from the display panel.
1. Follow the procedure in before working inside your computer.
2. Remove the base cover.
3. Remove the 3-cell battery or 4-cell battery.
4. Remove the display assembly.
5. Remove the display bezel.
6. Remove the display hinges.
About this task
The following images indicate the location of the display panel and provide a visual representation of the removal procedure.
Removing and installing components
91
