100 Hardware Overview
Table 3-7 shows the System LED definitions for the 8100-series switches.
Switch Addresses
The switch allocates MAC addresses from the Vital Product Data information
stored locally in flash. MAC addresses are used as follows:
Table 3-7. System LED Definitions—PowerConnect 8100-Series Switches
LED Color Definition
System Blinking blue The switch is booting
Solid red A critical system error has occurred.
Blinking red A noncritical system error occurred (fan or power
supply failure).
Temp Off The switch is operating at normal temperature.
Solid amber The thermal sensor’s system temperature threshold of
75°C has been exceeded.
Diag Off The switch is operating normally
Blinking green A diagnostic test is running.
Fan Solid green The fan is powered and is operating at the expected
RPM.
Solid red A fan failure has occurred.
Stack Solid blue The switch is in stacking master mode.
Solid amber The switch is in stacking slave mode.
Off The switch is in stand-alone mode.
Locator Blinking green The locator function is enabled.
Solid green The locator function is disabled.
Table 3-8. MAC Address Use
Base switch address
Base + 1 Out-of-band port
Base + 2 Layer 2
Base + 3 Layer 3
