574 Configuring VLANs

Figure 22-9. VLAN Settings for All Ports

VLAN LAG Settings

Use the VLAN LAG Settings page to map a LAG to a VLAN and to configure

specific VLAN settings for the LAG.

To display the LAG Settings page, click Switching

→

VLAN

→

LAG Settings

in the navigation panel.
