726 Configuring L2 Multicast Features

Return to the

VLAN Querier

page and select the new VLAN from the

VLAN ID

menu.

Specify the VLAN querier settings.

Click

Apply

The VLAN Querier settings are modified, and the device is updated.

To view a summary of the IGMP snooping VLAN querier settings for all

VLANs on the switch, click Show All.

Figure 26-19. Add VLAN Querier
