Figure 199. Installing the expansion card riser (Riser 1)
Next steps
1. If applicable, connect the cables to the expansion card or system board.
2. Install the GPU air shroud top cover.
3. Follow the procedure listed in After working inside your system.
4. Install any device drivers required for the card as described in the documentation for the card.
Removing a GPU
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system.
3. If applicable, disconnect the cables from the expansion card.
4. Remove the GPU air shroud top cover.
5. Remove the full length expansion card riser.
Steps
1. To remove the GPU from Riser 1:
a. Tilt the expansion card holder latch on the riser.
b. Press the tab, and pull the card holder from the riser.
c. Hold the GPU card by the edges and pull the card from the riser.
d. Disconnect the GPU power cable from the GPU card.
NOTE: The numbers on the image do not depict the exact steps. The numbers are for representation of sequence.
258 Installing and removing system components

Dell PowerEdge R760 Specifications

General

Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (4th Gen)
Memory	Up to 8TB DDR5
Drive Bays	Up to 24 x 2.5" SAS/SATA/NVMe (HDD/SSD)
Power Supply	Dual, hot-plug, redundant power supplies (800W, 1100W, 1400W options)
Network	1 x 1 GbE
RAID Controller	PERC H755, H355
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Microsoft Windows Server
