Dell PowerEdge R760 User Manual

Chassis dimensions
Figure 28. Chassis dimensions
Table 9. PowerEdge R760 chassis dimensions
Xa Xb Y Za Zb Zc
482.0 mm (18.97 inches) 434.0 mm (17.08
inches)
86.8 mm (3.41
inches)
35.84 mm (1.41
inches) With
bezel
22.0 mm (0.86
inches)
Without bezel
700.7 mm (27.58
inches) Ear to rear
wall
736.29 mm
(28.98 inches)
Ear to PSU
handle
NOTE: Zb is the nominal rear wall external surface where the system board I/O connectors reside.
System weight
Table 10. PowerEdge R760 system weight
System configuration Maximum weight (with all drives/SSDs)
A server with fully populated drives 36.1 kg (79.58 lbs)
A server without drives and PSU installed 25.1 kg (55.33 lbs)
Technical specifications 31

Dell PowerEdge R760 Specifications

General

Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (4th Gen)
Memory	Up to 8TB DDR5
Drive Bays	Up to 24 x 2.5" SAS/SATA/NVMe (HDD/SSD)
Power Supply	Dual, hot-plug, redundant power supplies (800W, 1100W, 1400W options)
Network	1 x 1 GbE
RAID Controller	PERC H755, H355
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Microsoft Windows Server
