Dell PowerEdge R760 User Manual

● 24 x 2.5-inch hot-swappable SAS or SATA, or NVMe drives
● 2 x 2.5-inch rear hot-swappable SAS, SATA, or NVMe drives
● 4 x 2.5-inch rear hot-swappable SAS, SATA, or NVMe drives
● Zero drives
NOTE: For more information about how to hot swap NVMe PCIe SSD U.2 device, see the Dell Express Flash NVMe
PCIe SSD User's Guide at https://www.dell.com/support > Browse all products > Infrastructure > Data Center
Infrastructure > Storage Adapters & Controllers > Dell PowerEdge Express Flash NVMe PCIe SSD > Select This
Product > Documentation > Manuals and Documents.
Ports and connectors specifications
USB ports specifications
Table 19. PowerEdge R760 USB specifications
Front Rear Internal (optional)
USB port type No. of ports USB port type No. of ports USB port type No. of ports
USB 2.0-
compliant port
One USB 2.0-
compliant port
One Internal USB 3.0-
compliant port
One
iDRAC Direct
port (Micro-AB
USB 2.0-
compliant port)
One USB 3.0-
compliant port
One
NOTE: The micro USB 2.0 compliant port can only be used as an iDRAC Direct or a management port.
NIC port specifications
The PowerEdge R760 system supports up to two Netwodk Interface Controller (NIC) ports embedded on the LAN on
Motherboard (LOM) card and up to four ports integrated on the Open Compute Project (OCP) card.
Table 20. NIC port specification for the system
Feature Specifications
LOM card (optional) 1 GbE x 2
OCP card (OCP 3.0) (optional) 1GbE x 4, 10 GbE x 2, 10 GbE x 4, 25 GbE x 2, 25 GbE x 4
NOTE: The system allows either LOM card or an OCP card or both to be installed in the system.
NOTE: On the system board, the supported OCP PCIe width is x8; when x16 PCIe width is installed, it is downgraded to x8.
Serial connector specifications
The PowerEdge R760 system supports one optional card type serial connector, which is a 9-pin connector, Data Terminal
Equipment (DTE), 16550-compliant.
The optional serial connector card is installed similar to an expansion card filler bracket.
VGA ports specifications
The PowerEdge R760 system supports DB-15 VGA port on front panel and on rear I/O board (optional for Direct Liquid Cooling
configuration).
Technical specifications
37

Dell PowerEdge R760 Specifications

General

Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (4th Gen)
Memory	Up to 8TB DDR5
Drive Bays	Up to 24 x 2.5" SAS/SATA/NVMe (HDD/SSD)
Power Supply	Dual, hot-plug, redundant power supplies (800W, 1100W, 1400W options)
Network	1 x 1 GbE
RAID Controller	PERC H755, H355
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Microsoft Windows Server
