Jumpers and connectors

This topic provides some basic and specific information about jumpers and switches. It also describes the connectors on the

various boards in the system. Jumpers on the system board help to disable the system and reset the passwords. To install

components and cables correctly, you must know the connectors on the system board.

Topics:

• System board jumpers and connectors

• System board jumper settings

• Disabling a forgotten password

System board jumpers and connectors

Figure 261. System board jumpers and connectors

Table 157. System board jumpers and connectors

Item Connector Description

1. Rear_I/O_connector Rear I/O connector

2. J_R3_PCIE_PWR Riser 3 power connector

314 Jumpers and connectors
