GPU kit
The GPU FL kit is available for the Customer. Depending on the kit ordered, the respective components are available.
CAUTION: Do not install GPUs, network cards, or other PCIe devices on your system that are not validated
and tested by Dell. Damage caused by unauthorized and invalidated hardware installation will null and void the
system warranty.
WARNING: Consumer-Grade GPU should not be installed or used in the Enterprise Server products.
Table 153. Components in the full length (FL) GPU kit
Components GPU FL kit
Details Quantity
Risers Riser configuration (RC)
3-2, 5-2*, or, 10-2*
RC 3-2: R1P
^
(FL) + R2A (HL) + R3B (HL) + R4P
^
(FL)
RC 5-2: R1R (FL) + R2A (HL) + R3A (FL) + R4P
^
(FL)
RC 10-2: R1P
^
(FL) + R2A (HL) + R4R (FL)
Shroud GPU shroud 1
Fans HPR GOLD fan 6
Heat sinks L-type heat sink
for processor 1 and
processor 2
RC 3-2, 5-2: 2
RC 10-2: 1
Cables Power cable 2 x 4 (8-position) or 2 x 6 + 1 x 4 (12-position + 4-sideband)
FL - Full Length, HL - Half Length, HPR - High Performance, RC - Riser configuration
NOTE: The power cable is imprinted with a silkscreen indicating which connector on the system board and to which GPU it
should be connected. Refer to the GPU power cable matrix table below for the power cable required for your GPU.
NOTE: Populate only processor 1 slot in RC10-2, as it only supports a single processor configuration.
NOTE: See expansion card installation guidelines for more information about riser configuration supported for the system.
NOTE: ^ R1P and R4P supports Double Width (DW) GPU.
NOTE: *The configuration 5-2 supports DW GPU only on slots 7 and configuration 10-2 supports DW GPU only on slot 2.
NOTE: All GPU cards require L-type heat sink and GPU shroud, irrespective of the length. However, the cooling fan and
foam are dependent on different configurations which is shown in below table.
Before you begin, follow the safety guidelines and before working inside the system instructions.
1. Remove the standard or High Performance Silver (HPR) cooling fans and install the High performance Gold (VHP) cooling
fans.
NOTE:
See the cooling fan and foam requirement matrix for the cooling fan and foam requirement for different
configurations.
Table 154. Cooling fan and foam requirement matrix
System configuration Cooling fan Foam requirement
w/GPU w/GPU
8 x 2.5-inch NVMe HPR GOLD No
8 x 2.5-inch NVMe + 8 x 2.5-inch SAS/SATA HPR GOLD Yes
16 x 2.5-inch SAS/SATA HPR GOLD Yes
Upgrade Kits 309
