1. Connect the battery cable to the system board.
2. Replace the two screws (M2x2) that secure the battery to the palm-rest and keyboard assembly.
3. Replace the screw (M1.6x4) that secures the battery to the system board and palm-rest and keyboard assembly.
1. Install the base cover.
2. Follow the procedure in After working inside your computer.
Coin-cell battery
Removing the coin-cell battery
1. Follow the procedure in Before working inside your computer.
CAUTION:
Removing the coin-cell battery resets the BIOS setup program’s settings to default. It is recommended
that you note the BIOS setup program’s settings before removing the coin-cell battery.
2. Remove the base cover.
3. Remove the battery.
The following image indicates the location of the coin-cell battery and provides a visual representation of the removal procedure.
Removing and installing components
15
