1. Align the notch on the solid-state drive with the tab on the solid-state drive slot and slide the solid-state drive into the solid-state drive
slot on the system board.
2. Slide the solid-state bracket on to the solid-state drive on the system board.
3. Replace the screw (M2x2.5) that secures the solid-state drive to the system board.
4. Adhere the mylar tape that secures the heat sink to the system board.
1. Install the battery.
2. Install the base cover.
3. Follow the procedure in After working inside your computer.
Heat sink
Removing the heat sink
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
The following image indicates the location of the heat sink and provides a visual representation of the removal procedure.
