System setup options
NOTE: Depending on the tabletcomputerlaptop and its installed devices, the items listed in this section may or may not
appear.
General options
Table 2. General
Option Description
System Information Displays the following information:
• System Information: Displays BIOS Version, Service Tag, Asset Tag, Ownership Tag,
Ownership Date, Manufacture Date, and the Express Service Code.
• Memory Information: Displays Memory Installed, Memory Available, Memory Speed,
Memory Channel Mode, Memory Technology, DIMM A size, and DIMM B size
• Processor Information: Displays Processor Type, Core Count, Processor ID, Current Clock
Speed, Minimum Clock Speed, Maximum Clock Speed, Processor L2 Cache, Processor
L3 Cache, HT Capable, and 64-Bit Technology.
• Device Information: Displays Primary HDD, ODD Device, M.2 SATA SSD, M.2 PCIe SSD-0,
LOM MAC Address, Video Controller, Video BIOS Version, Video Memory, Panel type,
Native Resolution, Audio Controller, Wi-Fi Device, and Bluetooth Device.
Battery Information Displays the battery status health and whether the AC adapter is installed.
Boot Sequence Allows you to specify the order in which the computer attempts to find an operating system from
the devices specified in this list.
Advanced Boot Options Allows you to select the Legacy Option ROMs option, when in UEFI boot mode. By default, no option
is selected.
• Enable Legacy Option ROMs
• Enable Attempt Legacy Boot
UEFI Boot Path Security This option controls whether or not the system will prompt the user to enter the Admin password
when booting a UEFI boot path from the F12 Boot Menu.
• Always, Except Internal HDD—Default
• Always
• Never
Date/Time Allows you to set the date and time settings. Changes to the system date and time take effect
immediately.
.
System information
Table 3. System Configuration
Option Description
Integrated NIC Allows you to configure the on-board LAN controller.
• Disabled = The internal LAN is off and not visible to the operating system.
• Enabled = The internal LAN is enabled.
• Enabled w/PXE = The internal LAN is enabled (with PXE boot) (selected by default)
SATA Operation Allows you to configure the operating mode of the integrated hard drive controller.
• Disabled = The SATA controllers are hidden
• AHCI = SATA is configured for AHCI mode
• RAID ON = SATA is configured to support RAID mode (selected by default)
64 System setup
