Delta VFD-V Series User Manual

VFD-V Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
8-6
Group 1: Basic Parameter
Control Mode
Parameters Functions Settings
Factory
Setting
VF VG SV SG T TG
01-00
Maximum Operation
Frequency
50.0~400.00Hz
60.00/
50.00
{ { { { { {
01-01
Maximum Voltage Frequency
(Base Frequency)
0.00~400.00Hz
60.00/
50.00
{ { { { { {
230V: 0.0~255.0V 220.0
01-02 Maximum Output Voltage
460V: 0.0~510.0V 440.0
{ { { { { {
01-03
Upper Midpoint Output
Frequency
0.00~400.00Hz 0.50
{ { ° ° ° °
230V: 0.0~255.0V 5.0
a
01-04
Upper Midpoint Output
Voltage
460V: 0.0~510.0V 10.0
{ { ° ° ° °
01-05
Lower Midpoint Output
Frequency
0.00~400.00Hz 0.50
{ { ° ° ° °
230V: 0.0~255.0V 5.0
a
01-06
Lower Midpoint Output
Voltage
460V: 0.0~510.0V 10.0
{ { ° ° ° °
01-07 Minimum Output Frequency 0.00~400.00Hz 0.00
{ { ° ° ° °
230V: 0.0~255.0V 5.0
a
01-08 Minimum Output Voltage
460V: 0.0~510.0V 10.0
{ { ° ° ° °
01-09 Startup Frequency 0.00~400.00Hz 0.50
{ { { { ° °
a
01-10 Upper Bound Frequency 0.0~110.0% 100.0
{ { { { { {
a
01-11 Lower Bound Frequency 0.0~100.0% 0.0
{ { { { ° °
a
01-12 The 1
st
Acceleration Time
0.00~600.00
/0.0~6000.0 Sec
10.00/
60.00
{ { { { ° °
a
01-13 The 1
st
Deceleration Time
0.00~600.00
/0.0~6000.0 Sec
10.00/
60.00
{ { { { ° °
a
01-14 The 2
nd
Acceleration Time
0.00~600.00
/0.0~6000.0 Sec
10.00/
60.00
{ { { { ° °
a
01-15 The 2
nd
Deceleration Time
0.00~600.00
/0.0~6000.0 Sec
10.00/
60.00
{ { { { ° °
a
01-16 The 3
rd
Acceleration Time
0.00~600.00
/0.0~6000.0 Sec
10.00/
60.00
{ { { { ° °
a
01-17 The 3
rd
Deceleration Time
0.00~600.00
/0.0~6000.0 Sec
10.00/
60.00
{ { { { ° °
a
01-18 The 4
th
Acceleration Time
0.00~600.00
/0.0~6000.0 Sec
10.00/
60.00
{ { { { ° °
