Delta VFD-V Series User Manual

5
VFD-V Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
5-1
CHAPTER 5 DESCRIPTION OF PARAMETER SETTINGS
5.1 Group 0: System Parameter
00-00 Identity Code Factory setting Read Only
Settings Based on the model type
00-01 Rated Current Display Factory setting Read Only
Settings Based on the model type
230V Series
Power [HP]
0.75
[1]
1.5
[2]
2.2
[3]
3.7
[5]
5.5
[7.5]
7.5
[10]
11
[15]
15
[20]
18.5
[25]
22
[30]
30
[40]
37
[50]
Model Code 4 6 8 10 12 14 16 18 20 22 24 26
Rated Current of the
Fixed Torque
5 7.5 11 17 25 33 49 65 75 90 120 146
Rated Current of the
Variable Torque
6.25 9.375 13.75 21.25 31.25 41.25 61.25 81.25 93.75 112.5 150 182.5
The Greatest Carrier
Wave Frequency
15KHz 10KHz
460V Series
Power [HP]
0.75
[1]
1.5
[2]
2.2
[3]
3.7
[5]
5.5
[7.5]
7.5
[10]
11
[15]
15
[20]
18.5
[25]
22
[30]
30
[40]
37
[50]
45
[60]
55
[75]
75
[100]
Model Code 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33
Rated Current
of the Fixed
Torque
3 4.2 6 8.5 13 18 24 32 38 45 60 73 91 110 150
Rated Current
of the Variable
Torque
3.75 5.25 7.5 10.625 16.25 22.5 30 40 47.5 56.25 75 91.25 113.75 137.5 187.5
The Greatest
Carrier Wave
Frequency
15KHz 10KHz 6KHz
 Pr. 00-00 and Pr. 00-01 offer the user the ability to verify the drive’s capacity and current
rating which has been preset by the factory.
Note 1: This parameter is read only.
Note 2: The factory setting is a constant torque rating. If a variable torque rating is desired,
please refer to Pr. 00-12.
