04-33 Process Control Operation Mode
a
Factory setting 00000
Bit setting 0
direction determined by Pr. 04-32
Bit 0
1
direction determined by the master speed control
2
0
1
0
continuously execute the process control operation
Bit 1
1
execute only one process control operation cycle
2
1
2
0
zero speed intervals disabled
Bit 2
1
zero speed intervals enabled
2
2
4
0
operate at zero speed upon time extension (note 1)
Bit 3
1
operate at a constant speed upon time extension (note 1)
2
3
8
0
PCO disabled
Bit 4
1
PCO enabled
2
4
16
Note: Please refer to Pr.02-01 to 02-06 and setting 23 “PCO time extension”.
04-34 Multi-Step Speed Operation Mode
a
Factory setting
00001
0
direction determined by Pr. 04-32
Bit 0
1
direction determined by the master speed control
2
0
1
0
continuously execute multi-step speed
Bit 1
1
execute multi-step speed based on time (Pr. 4-15 to
4-30)
2
1
2
0
zero speed intervals disabled
Bit setting
Bit 2
1
zero speed intervals enabled
2
2
4
Program operation
command
Program operation
indication
Step operation
indication
Program operation
fulfillment indication
