Delta VFD-V Series User Manual

B
VFD-V Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
B-1
ACCESSORIES
B.1 Non-fuse Circuit Breaker Chart
Per UL 508C, paragraph 45.8.4, part a,
For 3-phase drives, the current rating of the breaker shall be four times maximum of output
current rating.
(Note: According to our experience, we suggest to use 1.5 – 2 times maximum of output
current rating.)
3-phase
Model
Output Current (A)
Model
Output Current (A)
VFD007V23A 5 VFD150V23A 65
VFD007V43A 3 VFD150V43A 32
VFD015V23A 7.5 VFD185V23A 75
VFD015V43A 4.2 VFD185V43A 38
VFD022V23A 11 VFD220V23A 90
VFD022V43A 6 VFD220V43A 45
VFD037V23A 17 VFD300V23A 120
VFD037V43A 8.5 VFD300V43A 60
VFD055V23A 25 VFD370V23A 146
VFD055V43A 13 VFD370V43A 73
VFD075V23A 33 VFD450V43A 91
VFD075V43A 18 VFD550V43A 110
VFD110V23A 49 VFD750V43A 150
VFD110V43A 24
Fuse Specification Chart (
Smaller fuses than those shown in the table are permitted.)
Line Fuse
Model Input Current (A) Output Current (A)
I (A) Bussmann P/N
VFD007V23A 6.4 5 20 JJN-20
VFD007V43A 4 3 10 JJS-10
VFD015V23A 10 7.5 30 JJN-30
VFD015V43A 5.7 4.2 15 JJS-15
VFD022V23A 14.9 11 40 JJN-40
VFD022V43A 7.3 6 20 JJS-20
VFD037V23A 21.2 17 60 JJN-60
VFD037V43A 9.9 8.5 30 JJS-30
VFD055V23A 25.2 25 100 JJN-100
VFD055V43A 12.2 13 50 JJS-50
VFD075V23A 33.2 33 125 JJN-125
VFD075V43A 17.2 18 70 JJS-70
VFD110V23A 58 49 175 JJN-175
VFD110V43A
25 24 90 JJS-90
VFD150V23A
69 65 250 JJN-250
VFD150V43A 32 32 125 JJS-125
VFD185V23A 83 75 300 JJN-300
