XBee® Wi-Fi RF Modules
© 2013 Digi International, Inc. 8
1. Overview
The XBee® Wi-Fi RF module provides wireless connectivity to end-point devices in
802.11 bgn networks. Using the 802.11 feature set, these modules are interoperable
with other 802.11 bgn devices, including devices from other vendors. With XBee, users
can have their 802.11 bgn network up and running in a matter of minutes.
The XBee® Wi-Fi modules are compatible with other devices that use 802.11 bgn
technology. These include Digi external 802.11x devices like the ConnectPort products
and the Digi Connect Wi-SP, as well as embedded products like the ConnectCore series
and Digi Connect series of products. More information on these Digi products can be
found at:
http://www.digi.com/products/wireless/wifisolutions/
Specifications
General Specifications
Specification
XBee Wi-Fi
Through-hole
XBee Wi-Fi
Surface Mount
Dimensions
0.960 x 1.297
(2.438cm x 3.294cm)
0.866 x 1.330 in
(2.200 x 3.378 cm)
Operating Temperature -30 to 85° C
Antenna Options
PCB Antenna, U.FL Connector,
RPSMA Connector, or Integrated
Wire
PCB Antenna, U.FL Connector,
or RF Pad
RF Specifications
Specification
Frequency ISM 2.4-2.5GHz
Number of Channels 13
Adjustable Power Yes
Wi-Fi Standards 802.11 b, g, and n
Transmit Power Output
(Average)
Up to +16 dBm
(See table below)
FCC/IC Test Transmit
Power Range (Peak)
802.11g
802.11n (800 ns GI)
802.11n (400 ns GI)
7.87 to 28.52 dBm
8.03 to 28.75 dBm
8.04 to 28.64 dBm
802.11g
802.11n (800 ns GI)
802.11n (400 ns GI)
7.15 to 27.72 dBm
7.02 to 27.89 dBm
7.33 to 28.20 dBm
RF Data Rates
1 Mbps to 72.22 Mbps
(See table below)
Receiver Sensitivity
(25
, <10% PER)
-93 to -71 dBm
(See table below)
