XBee® Wi-Fi RF Modules
© 2013 Digi International, Inc. 92
RX (Receive) Packet: IPv4
Frame Type: 0xB0
This frame is used by XBee when RF data is received using the Serial Data service on the
port defined by the C0 command.
Example: When a module in API mode receives an IPv4 transmission, it will produce an
RX notification (0xB0) and send it out the UART or SPI. This example is the response to a
UDP transmission to IP address 192.168.0.103 with data ‘Hello’ from the source address
192.168.0.104.
Frame Fields Offset Example Description
API Packet
Delimiter
0 0x7E
Length
MSB 1 0x00
Number of bytes between the length and the
checksum
LSB 2 0x10
API Frame
Specific Data
API Frame
Identifier
3 0xB0
IPv4 32 bit
Source
Address
MSB 4 0xC0
The address in the example is for a source
address of 192.168.0.104
5 0xA8
6 0x00
7 0x68
16 Bit
Destination
Port
MSB 8 0x26
Same value as the C0 command.
LSB 9 0x16
16 bit
Source Port
MSB 10 0x26
LSB 11 0x16
Protocol MSB 12 0x00
0 = UDP, 1= TCP - Protocol use for the
transmitted data
Status 13 0x00 Reserved
RF Data
14 0x48 'H'
Up to 1400 bytes of data
15 0x65 'e'
16 0x6C 'l'
17 0x6C 'l'
18 0x6F 'o'
Checksum 19 0x13
0xFF minus the 8 bit sum of bytes from offset
3 to this byte.
