LP Engine G430(3.0L) Base Engine Service Procedure
Camshaft Bearing Removal
Tools Required
• J 6098-01 Camshaft Bearing Remover/Installer
1. Remove the camshaft rear bearing hole plug.
2. Use the J 6098-01 in order to remove the inner
camshaft bearings. Repeat the following procedure
for each of the inner camshaft bearings:
(1) With the nut (4) and the thrust washer (3)
installed to the end of the puller screw threads,
index the pilot (2) in the camshaft front bearing
and install the puller screw through the pilot (2)
and the bearing to be removed.
(2) Install the bearing tool (1) with the shoulder
toward the bearing.
(3) Using two wrenches, hold puller screw (5) while
you turn the nut (4) in order to draw the bearing
out of the bore.
(4) When the bearing has been pulled from the
bore, remove the bearing tool and the bearing
from the puller screw.
(5) Index the pilot in the rear camshaft bearing in
order to remove the rear inner camshaft
bearing.
3. Use the J 6098-01 in order to remove the front and
rear camshaft bearings.
(1) Assemble the bearing tool to the driver.
(2) Drive the front and rear camshaft bearings out
of the block bore. Drive inward toward the
center of the engine block.
VE055-3L
VE054-3L
