Doosan GC25P-3 User Manual

- 154 -
LP Engine G430(3.0L) Base Engine Service Procedure
2. Use the J 6098-01 in order to install the inner
camshaft bearings. Repeat the following steps for
each of the inner camshaft bearings:
(1) With the nut (4) and the thrust washer (3)
installed to the end of the puller screw threads,
index the pilot in the camshaft front bearing and
install the puller screw through the pilot (2).
(2) Index the camshaft bearing in the bore. Make
sure you align the oil galley holes.
(3) Install the puller screw through the bearing bore
and bearing to be installed and assemble
bearing tool (1) to the puller screw with the
shoulder toward the bearing. Make sure that
enough threads are engaged.
(4) Using two wrenches, hold the puller screw (5)
while you turn the nut in order to draw the
bearing into the bore. When the bearing has
been pulled into the bore, remove the bearing
tool and the puller screw and check the
alignment of the bearing oil hole to the bore oil
hole.
3. Install a new camshaft rear bearing hole plug. Coat
the plug outside diameter with GM P/N 1052080
sealant, or the equivalent.
Oil Pump Disassemble
1. If necessary, remove the oil pump screen.
• The oil pump screen has a press fit in to the pump
cover.
• Do not remove the screen from the pipe. The pipe
and screen are serviced as a complete assembly.
2. Remove the cover bolts.
3. Remove the pump cover.
VE083-3L
VE082-3L
VE054-3L
