- 170 -
LP Engine G430(3.0L) Base Engine Service Procedure
Crankshaft Pulley Installation
Tools Required
• J 8792 Crankshaft Pulley Installer
1. Coat the front cover oil seal contact area of the
crankshaft pulley with clean engine oil.
2. Assemble the J 8792 as shown.
3. Install the J 8792 onto the crankshaft pulley.
4. Position the pulley on the crankshaft and drive into
position until it bottoms against the crankshaft
sprocket.
Cylinder Head Installation
1. Install the new cylinder head gasket over the
locating pins.
2. Install the cylinder head over the locating pins and
the gasket.
3. Install the cylinder head bolts finger tight.
Tighten
Tighten the cylinder head bolts in sequence to 122
N•m (90 lb•ft).
VE115-3L
VE114-3L
VE113-3L
VE112-3L
To Next Page
